Key Features:

• Single AMD EPYC™ 7001/7002* Series Processor (*AMD EPYC 7002 series drop-in support requires board revision 2.x)
• 1TB Registered ECC DDR4 2666MHz SDRAM in 8 DIMMs
  2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs (Board revision 2.x required)
• Expansion slots:
  3 PCI-E 3.0 x16 (low profile);
  3 PCI-E 3.0 x8 (low profile)
  M.2 Interface: PCI-E 3.0 x4 (NVMe based)
  M.2 Form Factor: 2280, 22110
  M.2 Key: Onboard M-key
  Number of M.2: Single
• Integrated IPMI 2.0 + KVM with dedicated LAN
  • Software Out of Band License
   key (SFT-OOB-LIC) included
   for OOB BIOS management
• 2x 1GbE LAN ports via Intel^®I210
• 8 hot-swap 3.5" SAS3/SATA3 Drive Bays (on-board Broadcom3008 IRmode),
  1 M.2 NVMe SSD slot Supported
• 740W Redundant Platinum Level Power Supplies
  (Full redundancy based on configuration and application load)
