AS-1113S-WN10RT

  • • Virtualization
  • • Cloud Computing
  • • All Flash Storage
AMD
1 HE
1 CPU
16 DIMMs
10 Drives
2 x 10 GbE
Red. PSU
NVMe (optional)
SAS (optional)
Key Features:
  • Single AMD EPYC™ 7001/7002* Series Processor (*AMD EPYC 7002 series drop-in support requires board revision 2.x)
  • 2TB Registered ECC DDR4 2666MHz SDRAM in 16 DIMMs
    4TB Registered ECC DDR4 3200MHz SDRAM in 16 DIMMs (Board revision 2.x required)
  • Expansion slots:
    2 PCI-E 3.0 x16 (FH/HL) slots,
    1 PCI-E 3.0 x16 (LP) slot
    M.2 Interface: PCI-E 3.0 x2 (NVMe based)
    M.2 Form Factor: 2280, 22110
    M.2 Key: Onboard M-key
    Number of M.2: Dual
  • Integrated IPMI 2.0 + KVM with dedicated LAN
    • Software Out of Band License
     key (SFT-OOB-LIC) included
     for OOB BIOS management
  • 2x 10GBase-T LAN ports via BroadcomBCM57416
  • 10 hot-swap 2.5" U.2 NVMe drive bays,
    optional 4 SATA3 drive support with additional cables
  • 750W Redundant Power Supplies
    Platinum Level (94%)
    (Full redundancy based on configuration and application load)
