AS-2113S-WTRT

  • • Backup Storage
  • • Web or Database Servers
  • • Compact Network Appliance
AMD
2 HE
1 CPU
16 DIMMs
16 Drives
2 x 10 GbE
Red. PSU
NVMe (optional)
SAS (optional)
Key Features:
  • Single AMD EPYC™ 7001/7002* Series Processor (*AMD EPYC 7002 series drop-in support requires board revision 2.x)
  • 2TB Registered ECC DDR4 2666MHz SDRAM in 16 DIMMs
    4TB Registered ECC DDR4 3200MHz SDRAM in 16 DIMMs (Board revision 2.x required)
  • Expansion slots:
    1 PCI-E 3.0 x16 (FH/HL) slot,
    2 PCI-E 3.0 x8 (FH/HL) slots,
    2 PCI-E 3.0 x8 (LP) slots
    M.2 Interface: PCI-E 3.0 x2 (NVMebased)
    M.2 Form Factor: 2280, 22110
    M.2 Key: Onboard M-key
    Number of M.2: Dual
  • Integrated IPMI 2.0 + KVM with dedicated LAN
    • Software Out of Band License
     key (SFT-OOB-LIC) included
     for OOB BIOS management
  • 2x 10GBase-T LAN ports via BroadcomBCM57416
  • 16 hot-swap 2.5" SATA3 drive bays,
    or 10 hot-swap 2.5" SATA3 drive bays + optional 6 U.2 NVMe drive support with additional cables
  • 1200W Redundant Power Supplies
    Titanium Level (96%)
    (Full redundancy based on configuration and application load)
